| Cellular | |
| Technology | 4G LTE Cat 1 |
| Frequency | JC182-LA: LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28 JC182-EU: LTE-FDD: B1/B3/B7/B8/B20/B28; LTE-FDD: B34/B38/B39/B40/B41 |
| Interface | |
| LED indication | Red (Power), Blue (Cellular), Green (GNSS) |
| SIM | Nano-SIM |
| External memory | TF card (up to 512GB) |
| USB | Type-C |
| WiFi | 2.4GHz, Support WiFi Direct |
| Microphone | Support |
| Speaker | Support |
| Sensor | 3-Axis accelerometer |
| GNSS | |
| Positioning system | GPS, BDS, AGPS |
| Camera | |
| Front camera (main) | 2560×1440 / 25FPS / F2.4 / Full color / 110° (HFoV) |
| Video format | .ts |
| Power | |
| Input voltage | DC 9–30V |
| Operating environment | |
| Operating temperature | –20°C to +65°C |
| Storage temperature | –30°C to +85°C |
| Physical specification | |
| Dimensions | 70.0 x 60.0 x 34.0mm |
| Weight | 110g |
| Feature | |
| Configuration support | APP, Memory card |
| Firmware update | USB Cable, Memory card, OTA |
| Certification | CE, FCC |
| Standard Packing | |
| JC182 unit | 1 |
| Screws | 2 |
| Screwdriver | 1 |
| Optional Configuration* | |
| N/A | |
* Optional Configuration required to be customized or purchased separately.
** We reserve the right to the final interpretation of this page. All information is for reference only and is subject to change without further notice.
