| GNSS | |
| Positioning system | GPS+BDS+LBS |
| Positioning accuracy | ＜2.5m CEP |
| Tracking sensitivity | -165dBm |
| Acquisition sensitivity | -148dBm |
| TTFF (open sky) | Avg. hot start ≤1sec Avg. cold start ≤32sec |
| Cellular | |
| Communication network | LTE Cat 1/GSM; LTE Cat M1/Cat NB2 |
| Frequency | LL303-L LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 LTE-TDD: B40 GSM: B2/B3/B5/B8LL303-E LTE-FDD: B1/B3/B5//B7/B8/B20/B28 LTE-TDD: B38/B40/B41 GSM: B2/B3/B5/B8LL303-A Cat M1: B2/B4/B5/B12/B13/B25/B26/B66 Cat NB2: B2/B4/B5/B12/B13/B25/B66 GSM: B2/B3/B5/B8 |
| Power | |
| Battery | 10,000mAh/3.7V industrial-grade Li-Polymer battery |
| Solar power | 5V/400mA (Standard Operating Voltage/Current @STC) STC: Direct illumination with 38,000lux halogen lamp on the test bench. |
| Magnetic charger | 5V/2A |
| Working modes | Mode 1: Timing positioning mode Mode 2: Intelligent positioning mode Mode 3: Battery saving mode |
| Standby time | Up to 2 years in battery saving mode |
| Interface | |
| LED indication | Cellular (Green), Power (Red) |
| SIM | Nano-SIM |
| Tamper proof | Hall effect sensor |
| Physical specification | |
| Dimensions | 203x122x33mm |
| Weight | 548g |
| Operating environment | |
| Operating temperature | –20℃ to +70℃ |
| Operating humidity | 5%～95%, non-condensing |
| IP rating | IP67 |
| Feature | |
| Sensors | Accelerometer, Hall effect sensor |
| Scenarios | Low battery alert, Tamper alert, Vibrating Alert |
| Bluetooth | BLE 5.0 |
| RFID | 2.4GHz |
