| GNSS | |
| Positioning system | GPS+BDS+LBS |
| Positioning accuracy | ＜2.5m CEP |
| Tracking sensitivity | -162dBm |
| Acquisition sensitivity | -160dBm |
| TTFF (open sky) | Avg. hot start ≤1sec Avg. cold start ≤32sec |
| Cellular | |
| Communication network | LTE Cat 1/GSM |
| Frequency | VL802-E: LTE-FDD: B1/B3/B7/B8/B20/B28 LTE-TDD: B34/B38/B39/B40/B41 GSM: 850/900/1800/1900MHz VL802-L: |
| Power | |
| Battery | 1,000mAh/3.7V industrial-grade Li-Polymer battery |
| Input voltage | 9-36VDC |
| Interface | |
| LED indication | GNSS (Green), Cellular (Blue), Power (Red) |
| SIM | Micro-SIM |
| Data storage | 16+16MB |
| Digital inputs | ACC, SOS |
| Digital outputs | Relay |
| Configurable I/O | 2 special I/Os can be configured as extra digital inputs or outputs |
| Analog detect | Support 0-5V |
| Physical specification | |
| Dimensions | 105 x 56 x 22mm |
| Weight | 120g |
| Operating environment | |
| Operating temperature | –20℃ to +70℃ |
| IP rating | IP65 |
| Feature | |
| Sensors | Accelerometer |
| Scenarios | SOS alert, Speeding alert, Abnormal vibration alert, Fatigue driving alert |
